x-trap 50 LED

With its discreet design, the X-trap 50 LED is recommended for use in shops and restaurants and dry industrial environments. Easy to service, stylish and effective; the X-trap 50 LED offers it all.

WALL MOUNTING UNIT

  • Robust metal housing
  • Energy saving UV-A LED technology offers over 160 kW of savings per unit per year.
  • 3 year lifespan (25.000 hrs) of the UV-A LED lamps

SKU:

2.05.0600

Category:

LEDs

LED technology offers clear advantages in terms of efficiency (lower energy consumption) and its footprint (compactness)

Glueboards

Insects are caught on a glue layer, which preserves them over time. The caught insects can be counted and insect species can be analysed, which offers clear advantages in an IPM approach.

Recently special LED’s have entered the market, which have the ability to generate ultraviolet light; UV-A LED’s. These special LED’s form the heart of a new generation UV-A lamps; the ASTRON UV LED II 9 Watt lamp. This lamp replaces a traditional 15 Watt lamp and for this it only needs 9 Watts to offer the same UV-A output performance.

Advantages ASTRONUV LED II 9 Watt lamp

• The ASTRON UV LED II 9 Watt lamp is designed for low power consumption and high brightness.
• There are no harmful substances in the ASTRON UV LED II 9 Watt lamp.

Conclusion: It’s an eco-friendly product.

• The ASTRON UV LED II 9 Watt lamps complies to the int. standards and are perfectly save to use.
• Specially designed single ultraviolet wavelength, optimised for insect control. In other words, The perfect replacement lamp for the 15 Watt mercury lamp.
• The ASTRON UV LED II 9 Watt lamp does not require a ballast.
• The ASTRON UV LED II 9 Watt lamp only consumes 9 Watt and offers significant energy savings over the traditional 15 Watt lamp.
• The ASTRON UV LED II 9 Watt lamp has an operational lifetime of 25.000 hrs (3 years of constant use)
• The ASTRONUV LED II 9 Watt lamp uses class A LED’s which comply to the highest standards. Above all, this ensures a trouble free use.
• The ASTRONUV LED II 9 Watt lamp is executed in a full shatterproof executed design (no glass is used)
• Guarantee period: 2 years on electrical failures (mechanical defaults are excluded from guarantee)

www.alcochemhygiene.com for more products of Alcochem Hygiene.

Area coverage
Light source
Type of UV lamps
Electrical supply
Catch specifications
Power consumption
Weight
Degree of protection
Guarantee
Int. building norm
Lamp life time
Dimensions (L x D x H)
CE-approval
Mounting position
Cable
Packaging
Manual
Service
50 – 80 m2
2x 15 Watt UV-A LED lamps
UV LED Lamps RoHS certified
100-240 V ~ 50-60 Hz
By means of long life glue board
22 W
4,5 Kg
IP 20 (drip proof)
2 year return to base
acc. IEC-335-259 int. standard for insect exterminators
25.000 hrs (*)
538 x 103 x 311 mm
Yes
Wall mounted
Included
Export box included
Enclosed with the unit in English
Unit can be dismantled without special tools

(*) after 25.000 hours a loss of 30% in efficiency has to be expected and lamps need to be replaced

  • Robust metal housing
  • Energy saving UV-A LED technology offers over 90 kW of savings per unit per year.
  • 3 year lifespan (25.000 hrs) of the UV-A LED lamps
  • Environmental friendly: no restricted chemicals used in the product design.
  • RoHS / REACH / ISO and CB compliant
  • Fast and simple maintenance of the unit.
  • The glue rail system in the unit can hold diffently sized glue boards.
  • 2 years of guarantee
  • High quality casing offers over 5 years of operational use
  • Fast mounting and fast service
